0Cr21Al6Nb FeCrAl Alloy Heating Wire 1250ºC Max Temp

Brand Name : Tankii

Model Number : 0cr21al6nb

Place of Origin : China

MOQ : 10kg

Price : 7USD/kg

Payment Terms : D/P,T/T,D/A,L/C,Western Union,MoneyGram

Supply Ability : 1000kg Per Week

Delivery Time : 10-15days

Packaging Details : case

Resistivity : 1.25~1.53 Ω/M

Thermal Conductivity : 46.1 Kj/M.HºC

Maximum Temperature : 1250ºC

Specification : 0.02-7.5mm

Production Capacity : 1000kg Per Week

HS Code : 7506100000

Contact Now

0cr21al6nb Fecral Alloy Ferro Chrome Electric Heating Resistance Wire

1Cr13Al4, 0Cr25Al5, 0Cr23Al5, 0Cr21Al6, 0Cr21Al4, 0Cr21Al6Nb, 0Cr27Al7Mo2 is one kind of normal material of Fe-Cr-Al alloy.
FeCrAl alloy has the characteristic of high resistivity,low temperature resistance coefficient,high operating temperature,goodanti-oxidation and anti-corrosion under high temperature.
It is widely used in industrial furnace, household appliances, industry furnace, metallurgy, machinery, aircraft, automotive,
For other industries producing heating elements and resistance elements.

Alloy Nomenclature Performance 1Cr13AL4 0Cr25Al5 0Cr21AL6 0Cr23Al5 0Cr21Al4 0Cr21Al6Nb 0Cr27Al7Mo2

Cr 12.0-15.0 23.0-26.0 19.0-22.0 20.5-23.5 18.0-21.0 21.0-23.0 26.5-27.8

Al 4.0-6.0 4.5-6.5 5.0-7.0 4.2-5.3 3.0-4.2 5.0-7.0 6.0-7.0
Main Chemical composition Re opportune opportune opportune opportune opportune opportune opportune

Fe Rest Rest Rest Rest Rest Rest Rest







Nb0.5 Mo1.8-2.2
Max. continuous service temp. of element(ºC) 950 1250 1250 1250 1100 1350 1400
Resistivity at 20ºC(μΩ/m) 1.25 1.42 1.42 1.35 1.23 1.45 1.53
Density(g/cm3) 7.4 7.1 7.16 7.25 7.35 7.1 7.1
Thermal conductivity(KJ/m.h.ºC) 52.7 46.1 63.2 60.2 46.9 46.1 --
Coefficient of lines expansion(α*10-6/ºC) 15.4 16 14.7 15 13.5 16 16
Melting point approx.( ºC) 1450 1500 1500 1500 1500 1510 1520
Tensile strength(N/mm2) 580-680 630-780 630-780 630-780 600-700 650-800 680-830
Elongation at rupture(%) >16 >12 >12 >12 >12 >12 >10
Variation of area(%) 65-75 60-75 65-75 65-75 65-75 65-75 65-75
Repeat Bending frequency(F/R) >5 >5 >5 >5 >5 >5 >5
Hardness(H.B.) 200-260 200-260 200-260 200-260 200-260 200-260 200-260
continuous service time(Hours/ ºC) -- ≥80/1300 ≥80/1300 ≥80/1300 ≥80/1250 ≥50/1350 ≥50/1350
Micrographic structure Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite
Magnetic properties Magnetic Magnetic Magnetic Magnetic Magnetic Magnetic Magnetic

0Cr21Al6Nb FeCrAl Alloy Heating Wire 1250ºC Max Temp0Cr21Al6Nb FeCrAl Alloy Heating Wire 1250ºC Max Temp0Cr21Al6Nb FeCrAl Alloy Heating Wire 1250ºC Max Temp0Cr21Al6Nb FeCrAl Alloy Heating Wire 1250ºC Max Temp
