0.04mm To 0.5mm S Type Thermocouple Wire For High Temperature sensor
Introduction:
Type R, S, and B thermocouples are "Noble Metal" thermocouples, which are used in high temperature applications.
Type S thermocouples are characterized by a high degree of chemical inertness and stability at high temperatures. Often used as a standard for calibration of base metal thermocouples
Platinum rhodium thermocouple(S/B/R TYPE)
Platinum Rhodium Assembling Type Thermocouple is widely used in production places with high temperature. It is mainly used to measure temperature in glass and ceramic industry and industrial salting
0.04mm To 0.5mm S Type Thermocouple Wire For High Temperature sensor
Characteristics:
The thermocouple wires have excellent performance and are extensively used in the temperature measurement and control in different fields, such as metallurgy, chemical industry, petroleum industry, machinery-electric industry, energy industry, agriculture and military industry.
Tankii products conform to the standards of IEC584 -1and IEC-2.
Tankii Thermocouple strips, thermocouple connectors are available.
Tankii thermocouple grade extension wire can be supplied as per your request.
Tankii noble metal thermocouple alloy wire with class 1 and 2 are available.
Application Range of Tankii thermocouple wire:
1. Aerospace and Composites
2. Aluminum industry
3. Food and Pharmaceutical
4. Forgings
5. Glass, Ceramics, Clay Tiles, Bricks
6. Heat Treating
7. Petroleum, Downhole Oil & Gas
8. Sensor Manufacturing
9. Steel industry
10. Utilities Power Generation
0.04mm To 0.5mm S Type Thermocouple Wire For High Temperature sensor
Tankii noble metal Thermocouple Type and Temperature Range
| Thermocouple type and index
| Measurement Range ℃ |
| Type
| Index
|
|
PtRh30-PtRh6 | B | 600~1700 |
|
PtRh13-Pt | R | 0~1600 |
|
PtRh10-Pt | S | 0~1600 |
|
NiCr-NiSi | K | -200~1300 |
|
NiCr-CuNi (constantan) | E | -200~900 |
|
Fe-CuNi (constantan) | J | -40~750 |
|
Cu-CuNi (constantan) | T | -200~350 |
|
NiCrSi-NiSi | N | -200~1300 |
The allowable grade and Tolerance are obtained at 0℃
| Thermocouple
Type | Grade | Temperature range
℃ | Allowable Tolerance /℃ |
| Type B | Ⅱ | 600~1700 | ±0.25% t |
| Ⅲ | 600~800 | ±4 |
| 800~1700 | ±0.5%t |
| Type R(S) | Ⅰ | 0~1100 | ±1 |
| 1100~1600 | ±[1+(t－1100) ×0.3％] |
| Ⅱ | 0~600 | ±1.5 |
| 600~1600 | ±0.25% t |
| Type K and Type N | Ⅰ | -40~1100 | ±1.5℃ or ±0.4%t |
| Ⅱ | -40~1300 | ±2.5℃ or ±0.75%t |
| Ⅲ | -200~40 | ±2.5℃ or ±1.5%t |
| Type E | Ⅰ | -40~1100 | ±1.5℃ or ±0.4%t |
| Ⅱ | -40~1300 | ±2.5℃ or ±0.75%t |
| Ⅲ | -200~40 | ±2.5℃ or ±1.5%t |
| Type J | Ⅰ | -40~750 | ±1.5℃ or ±0.4%t |
| Ⅱ | -40~750 | ±2.5℃ or ±0.75%t |
| Type T | Ⅰ | -40~350 | ±0.5℃ or ±0.4%t |
| Ⅱ | -40~350 | ±1.0℃ or ±0.75%t |
| Ⅲ | -200~40 | ±1.0℃ or ±1.5%t |
Shanghai tankii, specializing in producing thermocouple wire, thermocouple cable, thermocouple MI cable.
A typical thermocouple construction consists of a pair of dissimilar metals that are electrically joined together at the sensing point and connected to a voltage measuring instrument at the other end. When one junction is hotter than the other, a thermal “electromotive” force (in millivolts) is produced that is roughly proportional to the difference in temperature between the hot and cold junctions.
0.04mm To 0.5mm S Type Thermocouple Wire For High Temperature sensor
Delivery and Packing of thermocouple wire:
1. Packaging Details : Carton box.
2. Leading time : 5 - 20 days, as the order quantity of thermocouple wire.
3. Delivery: By express, air, sea as per thermocouple wire qty
Welcome to call me or email to me for more information on S /B/R type thermocouple wire, Thermocouple cable, thermocouple flat wire, thermocouple strip.
